DW996 TYPE 3


Tool Diagram

Ordering Instructions:

Scroll down the page to the parts listing below.

Find the parts that you are looking for and enter the quantity needed in the boxes on the right of the page.

Click Add Parts to Cart button at the bottom of the page to add these items to your Shopping cart.

Contact Us:

Enter the following values in the field below: captcha
Fig # Part # Part Name Availability Price
1 151791-02 CLAMSHELL SET
Ships in 7-10 business days
$28.15
2 798954-00 WASHER REAR
Ships in 7-10 business days
$2.02
3 151936-02 GEAR,PLANET 1ST
Ships in 7-10 business days
$3.45
4 385408-00SV CARRIER
Ships in 7-10 business days
$13.29
5 393111-04 MOTOR & PINION
Ships in 7-10 business days
$72.72
6 284940-00 BRUSH BOX SET
Ships in 7-10 business days
$12.29
7 152274-19SV SWITCH- V.S.R.
2 in stock
$62.78
8 151678-00 BUTTON,FWD/REV
Ships in 7-10 business days
$1.20
9 150939-01 SHIFTER
Ships in 7-10 business days
$3.61
10 144658-00 SPRING
Ships in 7-10 business days
$1.05
11 799013-01 COLLAR ADJUST
Ships in 7-10 business days
$8.74
12 330075-59 KEYLESS CHUCK
Ships in 7-10 business days
$61.60
13 605256-01 CHUCK SCREW
12 in stock
$1.05
14 148354-03 CLIP BIT HOLDER
Ships in 7-10 business days
$1.05
15 607918-41 SCREWDRIVER BIT
Ships in 7-10 business days
$0.89
Fig # Part # Part Name Availability Price
16 330019-00 SCREW
Ships in 7-10 business days
$1.05
17 098091-10 SCREW, PAN HD
Ships in 7-10 business days
$1.05
18 330019-04 SCREW,PLASTITE
Ships in 7-10 business days
$1.04
19 608550-00 PLANET GEAR
Ships in 7-10 business days
$0.95
20 151681-00 VENT,AIR
Ships in 7-10 business days
$3.15
21 233308-00 DEWALT NP-SHEET
Ships in 7-10 business days
$2.70
22 395657-00 ID LABEL
Ships in 7-10 business days
$1.05
23 615824-12 UA BATTERY PACK 14.4V (NC1900 DC90
Ships in 7-10 business days
$82.69
24 385409-00 CARRIER
Ships in 7-10 business days
$12.90
25 805068-01 RING GEAR CHANGE 2 RED
Ships in 7-10 business days
$1.05
26 372274-00 GEAR PLANET 2ND
Ships in 7-10 business days
$2.96
27 798701-00 CASE GEAR
Ships in 7-10 business days
$8.36
28 284940-00 BRUSH BOX SET
Ships in 7-10 business days
$12.29
29 284940-00 BRUSH BOX SET
Ships in 7-10 business days
$12.29
30 152482-00 SEAL,FOAM
Ships in 7-10 business days
$1.05
Fig # Part # Part Name Availability Price
31 386154-00 CARRIER,OUTPUT
Ships in 7-10 business days
$12.90
32 392755-00 GEAR OUTPUT
Ships in 7-10 business days
$2.96
33 805063-02 GEAR RING
Ships in 7-10 business days
$4.46
34 370506-03 END CAP
Ships in 7-10 business days
$3.23
35 798966-01 NO LONGER AVAILABLE   $6.65 No Longer Available
36 805004-00 WASHER FLANGE
Ships in 7-10 business days
$2.25
37 798959-00 CLIP BEARING
Ships in 7-10 business days
$1.05
38 380792-00 PLATE DETENT
Ships in 7-10 business days
$4.46
39 380793-00 PIN
Ships in 7-10 business days
$1.20
40 798709-00 NUT ADJUSTING
Ships in 7-10 business days
$3.45
41 385490-00 SPINDLE,OUTPUT
Ships in 7-10 business days
$32.78
42 386690-00 BALL STEEL
Ships in 7-10 business days
$1.05
43 152347-00 SPRING
Ships in 7-10 business days
$1.05
44 395300-00 RETURN SPRING
Ships in 7-10 business days
$1.88
45 384917-00 RING CAM
Ships in 7-10 business days
$3.15
Fig # Part # Part Name Availability Price
46 798689-00 PLATE,THRUST
Ships in 7-10 business days
$2.04
47 799981-00 SPRING HAMMER
Ships in 7-10 business days
$1.75
50 380264-13 TRANSMISSION
Ships in 7-10 business days
$54.58
51 385475-00 NO LONGER AVAILABLE   $0.00 No Longer Available
800 N017298 GREASE
Ships in 7-10 business days
$65.19
861 652211-00 KITBOX
Ships in 7-10 business days
$21.46
871 388683-12 UA CHARGER 120V XRX3 DW9116
Ships in 7-10 business days
$88.57
