DW235G TYPE 3


Tool Diagram

Ordering Instructions:

Scroll down the page to the parts listing below.

Find the parts that you are looking for and enter the quantity needed in the boxes on the right of the page.

Click Add Parts to Cart button at the bottom of the page to add these items to your Shopping cart.

Contact Us:

Enter the following values in the field below: captcha
Fig # Part # Part Name Availability Price
1 176850-00 ARMATURE & FAN
Ships in 7-10 business days
$43.88
2 176848-00 FIELD
Ships in 7-10 business days
$30.92
3 176846-04 BRUSH
Ships in 7-10 business days
$2.92
5 176801-02 HOLDER,LT.BRUSH
Ships in 7-10 business days
$5.05
6 176800-02 HOLDER,RT.BRUSH
Ships in 7-10 business days
$5.05
7 621884-00 SWITCH
2 in stock
$34.09
8 N081018 CORDSET
1 in stock
$12.75
9 330003-04 BEARING
14 in stock
$9.20
10 330003-04 BEARING
14 in stock
$9.20
13 604996-01 FIELD CASE
Ships in 7-10 business days
$7.86
14 610142-02 HANDLE COVER
Ships in 7-10 business days
$4.92
15 176833-00 CLAMP,CORD
Ships in 7-10 business days
$1.61
16 330005-01 PROTECTOR,CORD
2 in stock
$4.23
18 176951-00 SCREW
Ships in 7-10 business days
$1.00
19 389824-00 CUP
Ships in 7-10 business days
$2.05
Fig # Part # Part Name Availability Price
20 176811-00 BAFFLE
Ships in 7-10 business days
$5.93
22 395047-00 ID LABEL
Ships in 7-10 business days
$1.00
23 N081026 NAMEPLATE
Ships in 7-10 business days
$0.91
25 176638-00 SPINDLE,OUTPUT
Ships in 7-10 business days
$18.03
26 330003-09 BEARING
1 in stock
$9.27
27 176691-00 SPACER
Ships in 7-10 business days
$2.14
30 176639-00 GEAR,OUTPUT
Ships in 7-10 business days
$18.03
32 605256-01 CHUCK SCREW
Ships in 7-10 business days
$1.00
34 449644-00 CHUCK 1/2 X 1/2-20 (33BA) W/KEY
Ships in 7-10 business days
$57.75
35 N081029 LEADWIRE ASSY.
Ships in 7-10 business days
$0.91
39 939794-00 HANDLE ASSY.
Ships in 7-10 business days
$15.10
48 87692-00 RING,RETAINING
Ships in 7-10 business days
$2.86
50 93128-00 BEARING,NEEDLE
Ships in 7-10 business days
$2.84
54 330004-00 BEARING,NEEDLE
Ships in 7-10 business days
$2.28
55 176647-00 SPINDLE&GEAR
Ships in 7-10 business days
$26.81
Fig # Part # Part Name Availability Price
57 91644-00 BEARING,THRUST
Ships in 7-10 business days
$4.46
58 330019-16 SCREW
Ships in 7-10 business days
$1.00
61 53650-00 TERMINAL
Ships in 7-10 business days
$0.95
62 176860-00 LEADWIRE
Ships in 7-10 business days
$1.00
63 176860-03 LEADWIRE
Ships in 7-10 business days
$1.33
80 330034-03 CHUCK KEY (K32)
5 in stock
$5.89
81 65288-01 CHUCK KEY HOLDER
2 in stock
$2.00
800 286436-00 GREASE
Ships in 7-10 business days
$91.29
862 629053-00 TOOL BAG
Ships in 7-10 business days
$22.01
